Copper Tape/Copper Strip

  • Grade: C1100, C1020, C1220, etc.
  • Thickness: 0.15mm - 3.0mm
  • Width: 8mm - 1000mm
  • Temper: O, 1/4H, 1/2H, 3/4H, H,SH,ESH
  • Product description: Shanghai Luthan is a professional manufacturer of Copper tape/ C11000, C10200/ Thickness: 0.15mm - 3.0mm
  • INQUIRY



Specifications of Copper Tape:


1) Grade: C11000, C12200, C1020


2) Chemical Composition: C1100: Cu >99.90%; C1020:

Cu >99.96%; C1220: Cu >99.90%; P 0.015-0.04%

3) Oxygen content: C1100: O < 500ppm; C1020: O < 50ppm

4) Temper: O, 1/4H, 1/2H, H

O: HV<70; 1/4H:HV 65-85; 1/2H:HV 80-100; H:HV >100

5) Electric Conductivity at 20℃: C1100/C1020 >97%; C1220 >80%



Feature:


1) Good electricity

2) Heat conduction

3) Being extruded and processed well

4) Good corrosion-resistance

5) Climate-hardiness

6) Good elongation

7) Being joined well by welding



Production Process Flow:

1.Melting Furnace

2.Continuous Casting Line & Slab Casting Line

3.Hot Rolling Mill

4. Reversing Cold Rolling Mill

5.Finish Rolling Mill

6.Pickling Line

7.Degreasing Line

8.Annealing Facility

9.Tension Leveler Line

10.Roll Grinding Machine




Application:

1) Commutators

2) Traction Motors

3) Earthening

4) Switchgear Products

5) Railway Electrification

6) Electrical Components

7) Panel Boards

8) Power Transformers

9) Connectors

10) Electrical Contacts
