Galvanized Steel Coil/Sheet/Strip

  • Hot Dip Galvanized Steel Sheet
  • Hot Dip Galvanized Steel Sheet
  • Hot Dip Galvanized Steel Sheet
  • Hot Dip Galvanized Steel Sheet
Hot Dip Galvanized Steel Sheet Hot Dip Galvanized Steel Sheet Hot Dip Galvanized Steel Sheet Hot Dip Galvanized Steel Sheet

Hot Dip Galvanized Steel Sheet

  • Thickness:0.12mm-5mm
  • Width:600mm-1500mm
  • Zinc coating: 30g/m2-600g/m2
  • Product description: Shanghai Luthan Metal is manufacturer of hot dip galvanized steel sheet, China Hot Dip Galvanized Steel Sheet distributor, China Hot Dip Galvanized Steel Sheet manufacture, Galvanized Steel Plate expo
  • INQUIRY

Specification of Hot Dip Galvanized Steel Coil:

Hot-dip galvanized steel sheet is known as hot dipped galvanized steel panel, hot dip galvanizing iron. Shanghai Luthan Metal can offer ASTM A653/M and ASTM A924M standard hot dip galvanized grade SGHC, SGCC, DX51D, with thickness range from 0.12mm to 5.0mm, and different gauge as customer required. Hot dip galvanized steel sheet specification normally have 4X8(1219mm*2438mm). It is mostly used for building materials, ventilation channel, home appliance, decoration, etc.. We can supplier hot-dip galvanized steel coil and sheet origin from China and from Bluescope with competitive price and excellent quality.


1) Capacity: about 15000 tons per month for the steel sheet and coil product
2) Grade: SGHC, SGCC, DX51D, Q195, all according to the customer's request
3) Standard: JIS G3302 1998, ASTM A653M/A924M 2004, all according to the customer's request
4) Thickness: from 0.12mm to 5.0mm, all available
5) Width: from 600mm to 1500mm, all available
6) Coil ID: 508mm/610mm
7) Coil weight: from 2-10MT, according to the customer's request
8) Zinc coating weight: 30g/m2-600g/m2, double side
9) Spangle : big spangle, normal spangle, small spangle, non-spangle
10) Surface treatment: Chemical passivating, oils, passivating + oils
11) Edge: mill edge, cut edge
12) Min trial order 10 ton each thickness, 1x20' per delivery
13)Surface Treatment of Hot Dip Galvanized Steel Coil:
Surface Treatment Features
Chemical passivating treatment minimize the chance of white rust forming during transit and storage
maintain the bright, shiny appearance for a longer time
Oils minimize the tendency for storage and transit stain
Passivating + oils provide the protection from storage and transit stain by special chemicals called corrosion inhibitors
14)Spangle of Hot Dip Galvanized Steel Coil:
Surface finish Pattern Application
Normal spangle Standard spangles with flower pattern General uses
Small spanlge Minimized spangles than regular General painting applications
Non-spangle Extremely minimized spangles Special painting applications

15) Features: Hot dip galvanized steel features excellent forming properties, paintability, weldability, and is suitable for fabrication by forming, pressing and bending. It is also Environmental Friendly resource because of its longevity in corrosion protection, low environmental cost, and 100% recyclability.
16) Product qualities:
>CQ - Commercial Quality steel for structural applications
>SQ - Structural Quality steel for applications that need more draw ability
>LFQ - Lock Forming Quality
>DQ - Drawing Quality
>DDQ - Deep Drawing Quality
